• Power: 50kW
• Photography kV: 50~125kV
• Photography mA scope: 50~500mA
• Exposure time: 5ms~6.3s
• Automatic organ procedures photography (APR)
• Supply conditions: 380VAC Three Phase
• Automatic fault diagnosis function

• Focus: 1.0mm/2.0mm
• Focus power: 30/50kW
• Anode heat capacity: 205kHU
• Rotating speed: 2800
• Anode target angle: 17.5°

• Radiation field: ≥430mm*430mm
• Aluminum filtration: 1.0mmAl
• Bed size: 2000mm × 665mm × 700mm
• Bed mobile range: Portrait 640mm, Transverse 200mm
• Bed bucky: Longitudinal travel ≥500mm

• Detector Type: Amorphous silicon
• Effective area: 17'×17'
• Pixel matrix: 3072×3072 | Pixel size: 139μm
• Spatial resolution: 3.6 lp/mm
• Acquisition time: 1.5s

• CPU: Dual-Core ≥2.7G 2M | Memory: ≥2GB DDRII
• Hard drive: 500GB | Monitor: ≥24 Inch LCD (1920*1200)
• Communication: ≥1000M NIC

• Full DICOM 3.0 compatibility (Send, Print, Storage)
• Advanced Image Processing: Tissue Equalization, USM sharpen, Wavelet noise reduction
• Workflow Support: WORKLIST query, automatic numbering, patient data retrieval
• Measurement Tools: Full suite of professional medical measuring and cutting tools
• Report System: Integrated medical illustrated report templates

After-sales Service: All products come with a comprehensive 12-month warranty. We maintain a dedicated team of engineers for after-sales technical support to ensure continuous operation and market reputation.

Packaging & Shipping: Standard export-grade packaging in wooden cases. Shipping typically arranged within ten days after payment confirmation.
