Key Features
Usage Areas: Orthopaedics (osteopathy, diaplasis, nailing), Surgery (foreign body removal, cardiac catheter, pacemaker implantation, interventional therapy).
- Compact appearance and easy to operate.
- Unique base electric auxiliary support arm design for enhanced security.
- Hand-held controller design for convenient operation.
- High-quality knockdown X-ray generator to minimize radiation.
- KV/MA automatic tracking fluoroscopy for optimum image brightness and clarity.
- Toshiba image intensifier for stable, reliable, and clear imagery.
- High-performance clinical video system with 8-image storage and high-resolution monitors.
- Dense grain grids installation to further enhance image sharpness.
⚙️
Technical Specifications
1. Fluoroscopic Capacity
Max rated capacity: Tube Current 4mA, Tube Voltage 120kV
Automatic Fluoroscopy: 40kV~120kV (Adjust Automatically)
Tube Current: 0.3mA~4mA (Manual Settings)
Pulse Fluoroscopy: 40kV~120kV, Current 4.1mA~8mA
2. Photography Capacity
Max rated capacity: 5 KW
Voltage Range: 40kV - 120kV
mAs Range: 1 ~ 180 mAs (based on kV setting)
Plate holder Size: 8″×10″ or 10″×12″
3. X-ray Tube
Fixed anode Dual-focus: Large focus: 1.5, Small focus: 0.3mm*0.3mm
Inverter Frequency: 40KHz
Thermal capacity: 35KJ (47KHU)
4. Video & Central Control
Image Intensifier: TOSHIBA (9″, 6″, 4.5″)
CCD Vidicon: Ultra low-light camera (Japan imported)
Monitor: 1000 lines horizontal / 800 lines vertical
CCU: Recursive Filter (K=8), 8 images storage, image overturn, LIH (Last Image Hold)
5. Mechanical Structure
Directive wheel: ±90° revolution for free direction changes
Pillar Range: ≥400mm
C-arm Movement: Forward/Backward 200mm
C-arm Revolution: Horizontal Axis ±180°, Vertical Axis ±15°
Orbit Slip: 120° (+90° to -30°)
❓
Frequently Asked Questions
Q1: How to buy your products?
You can place an order directly via our online platform or contact our sales team for assistance with configuration, shipping, and process guidance.
Q2: What's the payment mode?
We accept T/T Bank Transfer, Trade Assurance Service, Western Union, Money Gram, L/C, and Cash.
Q3: What's the delivery time and shipping method?
Lead time is generally within 1 week. We ship worldwide via express, air freight, or sea freight. Door-to-door service is available for many countries.
Q4: What's your after-sale service?
We provide at least a one-year warranty (excluding consumables) and lifetime technical support. Parts are provided at cost price after the warranty.
Q5: How do we secure transactions?
As a professional medical company with government certifications and verified premium status, all transactions are 100% guaranteed for your safety.
