| 1. Flat Panel Detector | |
| Type of the detector | TFT monolithic amorphous silicon |
| Panel size of the detector | 210mm*210mm |
| Acquisition pixel matrix | 1024×1024 |
| Pixel pitch | 200 um |
| Spatial resolution | 2.5LP/MM |
| 2. High Frequency and High Voltage Generator | |
| Max. Output power | 50kw |
| Photography voltage | 40~125kV |
| Continuous fluoroscopy mA | 0.5-5mA |
| Pulse fluoroscopy mA | 10-30mA |
| 3. X-ray Bulb Tube Assembly | |
| Focus | 0.3mm/0.6mm |
| Anode target angle | 12° |
| 4. C-Arm Stand | |
| Vertical displacement (electric) | ≥400mm |
| Horizontal displacement (manual) | ≥200mm |
| Rotation displacement (manual) | ≥±200° |
| Depth of arc | ≥650mm |
| S.I.D | ≥1000mm |
| 5. Workstation | |
| CPU | Intel i7, 3GHz or above |
| Host memory | ≥16GB DDR3 |
| Hard disk | 1T/7200rpm |
| Monitor | IPS LCD monitor |
| Windows System | Windows 10 64 bit Professional Edition |
