This advanced device is expertly designed to cater to the diagnostic needs of a wide range of animals, including bovine, equine, ovine, canine, feline, llama, swine, and other special animals, ensuring precision in ultrasonic diagnosis.
| No. | Functionality & Details |
|---|---|
| 1 | System Settings: Farm name, grayscale bar, pregnancy test display, grid, language (12 options), and recording duration (10s to 5min). |
| 2 | Patient Info: Input function for detailed record keeping. |
| 3 | Display Modes: Switching between B, B/B, and M modes. |
| 4 | Adjustments: Near-field (0 to -31dB), Far-field (0 to 31dB), Total gain (0 to 127dB), and Dynamic range (27 to 90dB). |
| 5 | Depth Range: 8 selection ranges; 6.5MHz probe (50mm-99mm), 4.0MHz probe (99mm-237mm). |
| 6 | Frequency: 4-frequency conversion function. |
| 7 | Body Marking: 27 markers for 7 categories (General, Cattle, Dog, Horse, Cat, Heart, Pig). |
| 8 | Measurement: Distance, circumference, area, volume, heart rate, and cycle measurement. |
| 9 | Obstetrics: 20 obstetric tables for 7 animal species, calculating gestational age and due date. |
